Bi-Directional Swing Gate Turnstile with 1200*280*1000mm Dimension 55-130CM Lane Width and AC 110~240V Power Supply
무료샘플과 쿠폰을 위해 나와 연락하세요.
왓츠앱:0086 18588475571
위챗: 0086 18588475571
스카이프: sales10@aixton.com
만약 당신이 어떠한 관심도 가지면, 우리가 24 시간 온라인 도움말을 제공합니다.
x제품 상세 정보
| 배리어 개방 시간 | 0.2 Ｓ | 통신 인터페이스 | RS-232, RS485, TCP/IP |
|---|---|---|---|
| 작동 방향 | 1가지 방식 | 배리어 모터 | 브러시리스 모터 |
| 보호 수준 | IP54 | 차원 | 1200*280*1000mm (l*w*h) |
| 차선 너비 | 55-130cm | 전원 공급 장치 | AC 110 ~ 240V 10% 50/60Hz |
| 주택 자료 | 304 스테인레스 스틸 | 스위치 전원 | AC220 ± 10%V 50Hz 또는 AC110 ± 10%V 60Hz |
| 팔 재료 | 10mm 아크릴, 강화 유리 또는 강철 | 패스 스루 너비 | 900mm |
| 적외선 센서 | 6 ~ 10 쌍 | 최적의 유량 | 40 명/분 (오픈), 35 명/분 (폐쇄) |
| 작동하는 습도 | 30%~95% | ||
| 강조하다 | 1200*280*1000mm Dimension Bi-Directional Swing Gate Turnstile,55-130CM Lane Width Bi-Directional Swing Gate Turnstile,AC 110~240V Power Supply Bi-Directional Swing Gate Turnstile |
||
제품 설명
Bi-Directional Swing Gate Turnstile for Gym Security Access Control
Manufactured with ESD features, this coin-operated turnstile provides secure access control for various facilities with its durable stainless steel construction and advanced functionality.
Applications
- Complete stainless steel construction suitable for interior or exterior installation
- Double core engine supports both sides access for multi-channel applications
- Provides security features including anti-pinch, time attendance, and passing management
- 485 interface for long-distance control
- IP54 rated for both outdoor and indoor use
- Operates smoothly with minimal noise
Technical Specifications
| 1 | Cabinet dimension | 1200 (L) x 280 (W) x 1000 (H) mm |
| 2 | Cabinet material | 304 stainless steel (316 ss can be custom-made) |
| 3 | Switching power supply | AC220±10%V 50Hz or AC110±10%V 60Hz |
| 4 | Opening/closing time | 0.2s |
| 5 | Arm material | Thickness 10mm Acrylic, or tempered glass or steel (custom) |
| 6 | Access mode | Single in/out or Bidirectional |
| 7 | Passthrough Width | 900mm (or custom) |
| 8 | Mechanism | DC Brushed motor+Clutch (or Servo motor) |
| 9 | Communication interface | RS485, TCP/IP |
| 10 | Infrared sensor | 6~10 pairs |
| 11 | Optimal flow rate | 40 persons/min (open), 35 persons/min (closed) |
| 12 | Reset time after break down | Default 10s (adjustable) |
| 13 | MCBF | 5,000,000 Cycles |
| 14 | Working humidity | 30%~95% |
Key Features
- Infrared reset function (Optional: 4 pairs or 6 pairs Infrared) with induction clamp function
- Bidirectional operation allowing entry and exit from one pair of turnstiles
- Real-time trouble self-detect and alarm indication for system safety
- Selectable normally open or close mode for effective passenger flow control
- Humanized reset function for over time passing
- Remote management capability via computer
- Flashing light prompt function for easy problem identification
Ideal Project Sites
Exhibition halls, Commercial buildings, Parks, Offices, Stadiums, Libraries, Museums
Product Advantages
- 16-hour professional customer service support
- 10+ years ODM/OEM experience with custom design capabilities
- Complete system solutions including software management
- Convenient repair service with video support and free spare parts within warranty
Frequently Asked Questions
Q: How long is your warranty period?
A: Standard one-year guarantee with lifetime technical support.
Q: How about the lead time?
A: Regular products: 7-10 working days; Customized products: 10-15 working days.
Q: What is the working environment?
A: Suitable for both indoor and outdoor use (with optional rain shed).
Q: Can I customize it?
A: Yes, we specialize in OEM/ODM services with extensive government project experience.
Company Information
Shenzhen Goldantell Technology Co.,Ltd is a leading exporter and supply chain service provider of intelligent turnstile, access control system and parking management products since 2007. We offer customized products and OEM services with new designs introduced annually.
Our Services & Strength
- Professional design team for OEM and ODM projects
- CE approved with successful European government project experience
- Experienced sales team with 4+ years in turnstile industry
- Competitive pricing with high quality standards and excellent after-sales service
- Custom solutions including complete access control systems
Pre-sale & After-sale Service
- Pre-sale: Detailed product consultation and information
- On-purchase: Regular production updates with photos and testing videos
- After-sale: Comprehensive installation and usage guidance
- OEM/ODM: Custom logo, size, color, and other specifications
- Professional support: 16-hour response to inquiries
