제품 상세 정보:
결제 및 배송 조건:
|
| 개찰구 크기: | 1200 밀리미터 (L) * 280 밀리미터 (W) * 1000 밀리미터 (H) | ESD 페달 크기: | 400mm (W) x 420mm (L) x 20mm (H) |
|---|---|---|---|
| 기록 용량: | 100,000 이상 | 정확성: | ± 5% |
| 재료: | 304 스테인레스 스틸 | 방향: | 한 개이거나 양방향입니다 |
| 통신 인터페이스: | RS485 | LCD 모니터 크기: | 8 인치 |
| 작동 전압: | 입력 AC220V 출력 DC12V | 작업 온도: | 5 ° C ~ 40 ° C |
| 테스트 범위: | 0.01-1000mΩ (신발), 0.1-35mΩ (손목 스트랩) | 전력 소비: | AC220V, 50HZ/AC110V, 60HZ |
| 순 중량: | 150kg | 패스 속도: | 30-40 명/분 |
| IP 보호: | IP54 | ||
| 강조하다: | 8-inch LCD ESD tester turnstile gate,stainless steel flap barrier gate,1200mm ESD tester turnstile gate |
||
| Attribute | Value |
|---|---|
| Item type | ESD Turnstile |
| Turnstile size | 1200mm (L) × 280mm (W) × 1000mm (H) |
| ESD pedal size | 400mm (W) × 420mm (L) × 20mm (H) |
| Recording information | Up to 100,000 or more |
| Accuracy | ±5% |
| Material | 304 stainless steel |
| Direction | Single or bi-directional (optional) |
| Access control system | Various access control compatible |
| Customization | Customized design, custom logo available |
| Communication interface | RS485 |
| Instrument Dimensions | 8 inch LCD monitor |
| Pedal size | 400mm (W) × 420mm (L) × 20mm (H) |
| Operating voltage | Input AC220V, Output DC12V |
| Working hours | Unlimited |
| Environmental conditions | Humidity: 0%~90%, Temperature: 5°C~40°C |
| Data storage | Automatically stores records and ESD test data (up to 100,000 or more) |
| Test Range and Accuracy |
Left shoe: 0.01-1000MΩ (±5%) Right shoe: 0.01-1000MΩ (±5%) Wrist-strap: 0.1-35MΩ (±5%) |
| Power consumption | AC220V, 50Hz/AC110V, 60Hz (optional) |
| Housing Size | 1200×300×1000mm |
| Housing material | 1.5-2mm, 304# stainless steel, corrosion resistant |
| Net Weight | 150KG |
| Drive motor | DC brushless motor |
| Channel width | 500-600mm |
| Pass speed | 30-40 persons/min |
| IP protection | IP54 |
| Input signal options | DC12V/dry/contact/RS485/RS232/Remote |
| Fail-safe operation | Railing-off against power off |
| Working temperature | -15°C to 75°C |
| Working environments | Indoor, outdoor |
| Relative humidity | ≤95% (non-condensing) |
| MCBF | 2,500,000 cycles |
We are a leading exporter and supply chain service provider of intelligent turnstile and parking management products with more than 8 years' experience.
Our product range includes intelligent turnstiles, parking barriers, RFID cards, sentry boxes, wheel clamps, and related security access control systems. We have exported to more than 50 countries worldwide.
We have successfully delivered turnstiles to over 50 countries including Brazil, Chile, Peru, Colombia, United States, Australia, Canada, and many European and Asian nations.
